Stainless Steel Seal Packing Machine Plastic Tray Packaging Sealing
Machine
RDS200:
Description:
Simply load the tray into the tray cavity, pull the film roll from
the back of the machine over the tray to completely cover the tray
,Pull down the handle of the heated top platen and apply pressure
to produce a seal,Release the handle and the top platen is spring
loaded and will Automatically return to the up position, remove
sealed tray to complete the sealing cycle.Features digital
temperature control and is constructed in 304stainless steel.
machine will run trays.
Applicantion:
Fresh meat, process meat, sea food, vegetable, agriculture
products, tea leaves, herbs, powder pices, prepard food
Electric parts, hard ware products, medical instruments, medicine
cloting and so on...
RDS200 desktop tray sealing machine is designed according to the
food needs of the modern taste, for packaging the food of different
tastes. It seals quickly. Packaged food does not drip, and has
health appearance.
This machine is a food tray sealing machine, suit for food catering
companies, fast food restaurants, hotels, tourist areas and other
places. It is convenient and hygienic, you can also carry home
taste without the soup overflow.
Application(Automatic Tray Sealing Machine):
It is suitable for food stores or small factories to seal the
products such as vegetable, quick meal, sauce etc.
Technical Characters of Automatic Cup or Tray Sealing Machine:
1. Suitable for vegetable, quick meal, sauce etc.
2. Suitable various material of film, such as PS, PP, aluminum
plastic composite film, Pre-cut foil etc.
3. Goodly superficies, Made by SS304;
4. Sanitary, convenience, quick sealing;
5. Sealing film could printed AD, and intensive propaganda;
6. Small bulk, light weight;
7. The date printer can be optional;
8. The tray of various sizes mould can be customized.
Common malfunction and solutions:
| NO. | malfunction | Reson | Solutions |
| 1 | The seal is incomplete or cannot be sealed | Damaged silicone strip in the lower mold holder | Replace the silicone strip |
| Oil or wrinkles on the surface of the packaging material | Cleans oil and treats wrinkles |
| The sealing temperature is unreasonable | Adjust according to the actual situation of packaging materials |
| Heating is not turned on | Turn on heating |
| Not enough sealing pressure or time | Increase sealing strength and sealing time |
| Box and film materials do not match | Replace the box or film material |
| 2 | Heating mold "sticky box" | The hot ironing board has dirt | After the machine stops and waits for the upper mold to cool, use a
cleaning cloth dipped in alcohol to clean and remove surface dirt |
| There are foreign objects on the surface of the sealing film | Clean up foreign objects |
| The non-stick layer on the surface of the heating ironing board
falls off | After the machine stops and waits for the upper mold to cool,
remove the hot plate and send it back to the company to re-spray
the non-stick layer |
| Heat seal temperature is set too high | Adjust heat sealing temperature |
| Temperature probe short circuit | Turn off the power and check if the heating circuit is shorted |
| 3 | Film cut continuously | Cutter blade deformed curling tooth | After the machine stops and waits for the upper die to cool down,
remove the cutter and straighten the cutting edge of the winding
tooth. If it still cuts continuously, replace the cutter |
| The width of the film is not enough to hold the film | Replace the appropriate width film |
| The thin film silicone strip is damaged and the film is not
compressed | Replace the upper molded silicone strip |
Startup and equipment operation:
Step 1: Turn on the main power switch of the device until the power
switch turns on
Step 2: Seal the device
2.1 Set temperature: Press the up and down keys on the temperature
control display (see Figure 1.1) to increase or decrease the
temperature to a suitable temperature.
2.2 Place the tray in the lower model cavity, pull the film to
completely cover the upper surface of the box to a suitable
position, hold the handle and press the upper mold down firmly,
press it to the lowest point, and stabilize it for 3-4s Adjust the
arm strength), then loosen the upper mold and raise it to the
initial position. Such a reciprocating cycle can complete a batch
of box sealing and film cutting;
Step 3: When you do not need to use the device, just turn off the device
power switch.
